NG waterproof flange bearing F4 Ø50, 4-bolt, closed cover

NG50F40

The NG50F40 is a robust and hygienic flange bearing tailored for heavy-duty industrial applications. It features a 4-bolt flange design and an open end cover, allowing quick inspection and simplified maintenance.

Manufactured with a polyurethane housing, this bearing offers high resistance to corrosion, cleaning agents, and mechanical stress. The IP66 classification ensures the unit is fully waterproof and ideal for operation in wet or washdown environments. The shaft size is Ø50 mm, suitable for a wide range of industrial setups.

Housing material: Polyurethane
Flange type: 4-bolt
Cover type: Open
Shaft size: Ø50 mm
IP rating: IP66 – Waterproof and washdown resistant

€130.00

Excluded taxes and delivery costs

Made to order

Expected shipment:

Estimated Shipping:

Accessories

Grease nipple None
Shaft size (mm) Ø50
Sealing Nitrile rubber (NBR)
Mounting Eccentric
Country of origin CHN

NG insert bearing PE Ø50, stainless steel BJ item number: KI805050

€78.00

excl. VAT

Grease nipple 45°
Country of origin CHN

NG waterproof grease nipple 45 degrees, stainless steel BJ item number: KI820015

€3.42

excl. VAT

Grease nipple 90°
Country of origin CHN

NG waterproof grease nipple 90 degrees, stainless steel BJ item number: KI820020

€4.26

excl. VAT

Description

Key features:

Cleaning it is quick and easy. The flange housing has a compact shape, with no sharp edges or rough surfaces.
The bearing does not need lubrication. The bearing has a special ball made of PE, with a locking device that keeps it in place. It lasts for a long time without needing any maintenance.
The flange housing has a ring that seals it tightly, with a spring made of stainless steel. This stops water from getting inside the housing.
The flange housing has a high IP rating, which means it can withstand dust and water.
Installation is easy. The flange housing has four holes for mounting, just like other flange housings on the market.
Maintenance is not needed. The bearing doesn't need any lubrication or upkeep. It works smoothly without any trouble.

Materials:

The flange housing has a grease nipple made of stainless steel, which allows optimal filling with food-grade grease.
The flange housing is made of PUR.
