Description
Key features:
- Screw set lock: The bearing unit is mounted with a screw set lock mechanism, providing stability.
- Maintenance-free operation: This bearing unit is designed for minimal maintenance, requiring only regular greasing when needed.
- Wide operating temperature range: From -20° C to +120° C.
- No surface coating required: The stainless steel construction eliminates the need for additional surface coatings, making the bearing unit resistant to corrosion and prolonging its lifespan.
Materials:
- Stainless steel housings: The housing of the bearing unit is made of AISI 304 stainless steel.
- SUC stainless steel bearings: The bearings used in this unit are made of AISI 440C stainless steel.
- Stainless steel grease nipple: The bearing unit can be easily re-lubricated using a stainless steel grease nipple.
Specifications
Grease nipple
Straight
Hole distance (mm)
130
Shaft size (mm)
Ø35
Cover
Open
Sealing
Nitrile rubber (NBR)
Bearing material
Stainless steel
Model
SFL
Mounting
Set screw
Housing type
2-bolt flange bearing
House material
Stainless steel
Country of origin
CHN
HS-Code
84832000.000000
ERP net weight (Kg)
1.140000
Foreign trade
HS-Code
84832000
ERP net weight (Kg)
1.14
Country of origin
CHN
